Solé Marine Engine Sm-82 With Gearbox Tm93, R=2.77:1

The Solé SM-82 is a turbocharged 4-stroke inboard marine diesel engine based on a Mitsubishi engine block. This four-cylinder in-line engine delivers a maximum output of 82 hp (60.3 kW) according to the ISO3046/1 standard at 2,500 rpm. The engine features a displacement of 3,331 cc, a bore and stroke of 94 x 120 mm, a compression ratio of 22:1, and a maximum torque of 268 Nm at 1,350 rpm. The combustion system utilizes indirect mechanical injection, and cooling is managed via an intercooler with a heat exchanger. The engine allows for a maximum installation angle of 12° (+3° discontinuous).

The 12V electrical system includes a 2.2 kW starter motor and a 95A alternator. Connection diameters are 76 mm for the exhaust, 32 mm for the cooling water inlet, 8 mm for the fuel inlet, and 8 mm for the fuel return. This specific model (article number 9022638) has a weight of 362 kg (measured including TM345) and comes equipped with a hydraulic Technodrive TM93 gearbox featuring a reduction ratio of 2.77:1. The scope of delivery includes exclusively the individual engine with the specified gearbox.
