Johnson Pump L-Series Bilge Pump (Cartridge Typ) L650, 24v/1,6a, 61l/Min, Max. Head 3,5m
Article number
663216500124
Description
The Johnson Pump L-series bilge pump (cartridge type) L650 (article number: 663216500124, EAN: 8719182072768) is designed for pumping applications. The product weighs 0.27 kg, has a height of 112 mm, and a diameter of Ø70 mm. The pump operates on a 24V voltage with a current draw of 1.6A (fuse rating: 5A, current consumption up to 3.2A). The maximum head height is 3.5 metres. It offers a straight-flow capacity of 61 l/min and a capacity of 53 l/min at a 1-metre head height. The unit features a lip seal, a 3/4" hose connection, and a cable diameter of 0.75 mm².
Scope of Delivery:
This item is supplied as a standalone bilge pump (1 piece).
Files
Properties
General
| Articlenumber | 663216500124 |
| EAN number | 8719182072768 |
Pumps
| Ampere | 3,2A |
| Weight | 0,27kg |
| Voltage | 24V/1,6A |
| Diameter | Ø70mm |
| Connection | 3/4’’ |
| Fuse | 5A |
| Capacity | 1m head - 53l/min |
| Capacity straight | 61l/min |
| Max. Head | 3,5m |
| Height | 112mm |
| Seal | Lip Seal |
| Elecric Cable | 0,75mm2 |
